OMNIVSINT1500XL
Tripp Lite
Tripp Lite, UPS, OmniVS 1500VA, 230V, 940W, Tower, Intl, AVR, 8 x C13 Outlets, USB Port, RJ11, RJ45
The Tripp Lite Omni VS 1500VA UPS is sleek and modern looking. It is powerful yet small enough to be easily portable. This tower UPS can allow time to save work in case the electricity goes out. It can be ideal for those who use desktop computers. It can provide you with a sustainable power source and has a five-minute full load. It can be color coordinated to blend with your design.
Specifications
| details | OUTPUTOutput Volt Amp Capacity (VA):1500Output kVA capacity (kVA):1.5Output Watt Capacity (watts):940Nominal Output Voltage(s) Supported:230VFrequency compatibility:50 / 60 HzOutput voltage regulation (line mode):-18%, +8%Output voltage regulation (Battery mode):+/- 5%Built-in UPS output receptacles:8 C13 outlet(s) Included output power cables:Includes 2 C13 to C14 output power cablesBasic PDU options:PDUNV (1U / 2 C19, 12 C13 outlets) Switched PDU options:PDUMH15HVNET (1U / 8 C13 outlets) Output AC waveform (AC mode):Sine waveOutput AC waveform (battery mode):PWM sine wave INPUTRated input current (at maximum load):5ANominal Input Voltage(s) :Supported230V ACUPS input connection type:C14 inletUPS input connection description:Attached 15cm line cord with C14 inlet. The C14 inlet accepts user-supplied AC power cord with country-specific plug. UPS Input cord length (ft.):0.5UPS Input cord length (m):0.2 BATTERYFull load runtime (minutes):4.5 min. (940w) Half load runtime (minutes):13 min. (470w) Expandable battery runtime:Extended runtime supported via optional external battery packsExternal battery pack compatibility:BP24V15RT2U (limit 1) BP24V28-2U (limit 1) BP24V70-3U (multi-pack compatible) DC system voltage (VDC):24Battery recharge rate (included batteries):Less than 4.5 hours from 10% to 90%Replacement battery cartridge (internal UPS battery replacement):RBC51 (quantity 2) Battery Access:Battery access doorBattery replacement description: Hot-swappable, user replaceable batteries VOLTAGE REGULATIONVoltage regulation description:Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 151 to 282Overvoltage correction:Input voltages between 245 and 282 are reduced by 12%Undervoltage correction:Input voltages between 177 and 199 are boosted by 14%Severe undervoltage correction:Input voltages between 151 and 176 are boosted by 30% LEDS ALARMS and SWITCHESLED Indicators: 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace statusAlarms:Audible alarm indicates power-failure and low-battery conditionsAlarm cancel operation: Power-fail alarm can be silenced using alarm-cancel switch once silenced, alarm will re-sound to indicate low-battery statusSwitches:2 Switches control off/on power status and alarm-cancel/self-test operation SURGE / NOISE SUPPRESSIONUPS AC suppression joule rating:340UPS AC suppression response time:InstantaneousUPS Dataline suppression:1 line TEL/DSL (1 in / 1 out) 10/100Base T EthernetEMI / RFI AC noise suppression:YesLINE / BATTERY TRANSFERTransfer time:2-4 millisecondsLow voltage transfer to battery power (setpoint):151High voltage transfer to battery power (setpoint):282 CERTIFICATIONSUPS Certifications:Tested to UL1778 (USA) Tested to CE (EU) Tested to GOST (Russia) Tested to SASO (Saudi Arabia) Tested to IRAM (Argentina) UPS Certification details:CE 62040 Item Dimension (L"xW"xH"): 11.25 x 11 x 15.5 Weight:35 lb Warranty Information: 2 Years |
Available From 1 Seller
| Seller | Condition | Qty | Price | Location | Updated | Action | |
|---|---|---|---|---|---|---|---|
|
Aztek Computers
VAR |
Refurbished | 1 | $427.40 | Frisco, TX | Mar 18 |
