ICUSB234858I

STARTECH

USB to RS232/RS485/RS422 8 Port Serial Hub Adapter - Industrial Metal USB 2.0 to DB9 Serial Converter - Din Rail Mountable - Industrial 8 port serial hub 15kV Level 4 ESD - IP30 rating Metal USB to serial adapter converter w/ each DB9 port set to RS232/RS422/RS485(2wire/4wire) baud rates up to 921.6Kbps - Desk/wall/DIN rail mount - 6ft USB cable - 12V power adapter/5V USB

8-Port Industrial USB to RS-232 SpecificationsHost interface: USB 2.0Ports quantity: 8Hub interfaces: SerialUSB 2.0 ports quantity: 2Data bits: 7, 8Stop bits: 1, 2Baud rate: 921.6 Kbit/sParity bit: Even, Mark, N, Odd, SpaceSurge protection: YPower source type: ACPower consumption (typical): 36 WInput voltage: 100-240Input current: 1Output voltage: 12 VOutput current: 3 APlug type: Type MLED indicators: PowerMaterial: SteelWindows operating systems supported: Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64Mac operating systems supported: Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.9 MavericksOperating relative humidity (H-H): 5 - 95%Cables included: USBCertification: CE, FCC, TAA, RoHSOperating temperature (T-T): 0 - 55 CStorage temperature (T-T): -20 - 85 CIncluded power plug types: ANZ,EU,UK,USChipset: FTDI - FT4232H, Genesys Logic - GL825Weight: 3.44 lbs- SKU: SYBA31934
Specifications
detailsGeneral InformationManufacturer:StarTech.comManufacturer Part Number:ICUSB234858IManufacturer Website Address:http://www.startech.comBrand Name:StarTech.comProduct Name:USB Serial HubMarketing Information:Add extra COM ports to your laptop or desktop computer, quickly and easily. This USB to RS232/422/485 serial adapter lets you connect to your serial devices through an external USB port. Supports multiple serial protocols The versatile serial adapter converts a single USB port into eight RS232/RS422/RS485 serial ports, enabling you to connect, monitor, and control a wide range of serial devices, such as sensors, barcode scanners, and LED signage. It supports four operating modes, including RS232, RS422, 4-wire and 2-wire RS485. Ideal for harsh environments With its rugged IP30-rated metal hub housing, the serial adapter is built to meet the extreme demands of harsh and mission-critical environments. It provides 15 kV ESD protection, which helps to reduce downtime in industrial environments where communications lines are more prone to noise emissions or sudden spikes in voltage. The serial adapter offers flexible mounting options, with a built-in wall-mounting bracket and included DIN rail mounting kit. It also features a screw-locking host connection plus a screw-locking USB-B connector on the included USB cable, to prevent accidental disconnections. Fast data transfers The serial adapter is equipped with high-speed UARTs, providing fast data rates of up to 921Kbps in RS232/422/485operating modes. The ICUSB234858I is backed by a StarTech.com 2-year warranty and free lifetime technical support.Packaged Quantity:1Product Type:Serial HubTechnical InformationHost Interface:USBPlatform Supported:PCLinuxInterfaces/PortsNumber of Serial Ports (External):8Physical CharacteristicsForm Factor:ExternalHeight:1"Width:5"Weight (Approximate):1.52 lbMiscellaneousPackage Contents: USB Serial Hub 1 x USBxB with Screw Lock to USBxA Cable 1 x DIN Rail Kit 1 x Universal Power Adapter (NA/JP, UK, EU, ANZ) 1 x Instruction Manual Environmentally Friendly:YesEnvironmental Certification:RoHSWEEEREACHCountry of Origin:TaiwanTAA Compliant:YesWarrantyLimited Warranty:2 Year
1
Seller
22
In Stock
$437.31
From
Watch This Product
Available From 1 Seller
Seller Condition Qty Price Location Updated Action
Aztek Computers
VAR 		Refurbished 22 $437.31 Frisco, TX Mar 18
