SMART1000RM1U

<p>Protects connected mission-critical equipment against damage, downtime and data loss due to blackouts, brownouts, power surges and line noise.</p><br /><br /><ul><li>UPC Code: 037332118820</li><li>UPS Type: Line-Interactive</li><li>Input Phase: Single-Phase</li><li>Rated input current (Maximum Load): 9A</li><li>Nominal Input Voltage(s) Supported: 120V AC</li><li>UPS Input Connection Type: 5-15P</li><li>Input Circuit Breakers: 15A</li><li>Recommended Electrical Service: 15A 120V</li><li>Input Cord Length (ft.): 10</li><li>Output Capacity (VA): 1000</li><li>Output Capacity (kVA): 1</li><li>Output Capacity (Watts): 800</li><li>Output Capacity (kW): 0.8</li><li>Power Factor: 0.8</li><li>Nominal Voltage Details: 120v nominal output in battery mode</li><li>Frequency Compatibility: 60 Hz</li><li>Output Voltage Regulation (Line Mode): -21%, +8%</li><li>Output Voltage Regulation (Battery Mode): +/- 5%</li><li>Load Management Receptacles: Two switchable single-outlet 5-15R load banks</li><li>Output AC Waveform (AC Mode): Sine wave</li><li>Output AC Waveform (Battery Mode): Pure Sine wave</li><li>Nominal Output Voltage(s) Supported: 110V; 115V; 120V</li><li>Output Receptacles: (6) 5-15R</li><li>Individually Controllable Load Banks: Yes</li><li>Battery Type: Valve Regulated Lead Acid (VRLA)</li><li>Runtime Full Load (min.): 4 min. (800W)</li><li>Runtime Half Load (min.): 14 min. (400W)</li><li>DC System Voltage (VDC): 24</li><li>Battery Recharge Rate (Included Batteries): 4.5 hours from 10% to 90% (typical, full load discharge)</li><li>Battery Access: Front panel battery access door</li><li>Internal UPS Replacement Battery Cartridge: RBC69-1U </li><li>Battery Replacement Description: Hot-swappable, user replaceable batteries</li><li>Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147</li><li>Overvoltage Correction: Input voltages between 128 and 147 are reduced by 12%</li><li>Undervoltage Correction: Input voltages between 83 and 107 are boosted by 14%</li><li>Switches: 2 Switches control off/on power status and alarm-cancel/self-test operation</li><li>Alarm Cancel Operation: Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status</li><li>Audible Alarm: Audible alarm indicates power-failure, overload and low-battery conditions</li><li>LED Indicators: 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status</li><li>UPS AC Suppression Joule Rating: 450</li><li>EMI / RFI AC Noise Suppression: Yes</li><li>AC Suppression Response Time: Instantaneous</li><li>Primary Form Factor: Rackmount; Vertical</li><li>Rack Height: 1U</li><li>Cooling Method: Fan</li><li>Included Mounting Accessory Description: Included mounting brackets provide front-rail installation in 2 or 4 post racks; For additional stability in 4 post racks, consider optional 4 post mounting accessories 4POSTRAILKIT1U &amp; 4POSTRAILKITWM</li><li>Installation Form Factors Supported with Included Accessories: 2 post 19 inch rackmount; 2 post front mount; 4 post 19 inch rackmount</li><li>Installation Form Factors Supported with Optional Accessories: Vertical Mount Enclosures ( SRWF5U36 , SRWF5U , SRWF10UMOD )</li><li>Minimum Required Rack Depth (inches): 20</li><li>Optional Mounting Accessory Notes: Optional 4POSTRAILKITWM enables installation in 4-port short-depth racks from 14.5 to 23.5 inches (368 to 597mm); Optional 4POSTRAILKIT1U enables installation in 4-post full-depth racks from 20.5 to 36 inches (521 to 914mm)</li><li>Primary UPS Depth (mm): 425</li><li>Primary UPS Height (mm): 44</li><li>Primary UPS Width (mm): 445</li><li>Shipping Dimensions (hwd / in.): 5.30 x 21.30 x 22.90</li><li>Shipping Weight (lbs.): 34.75</li><li>UPS Housing Material: Steel</li><li>UPS Power Module Dimensions (hwd, in.): 1.75 x 17.5 x 16.75</li><li>UPS Power Module Weight (kg): 14.51</li><li>UPS Power Module Weight (lbs.): 32</li><li>Unit Weight (lbs.): 32.0000</li><li>Operating Temperature Range: 32r to 104rF (0r to 40rC)</li><li>Storage Temperature Range: 5r to 122rF (-15r to 50rC)</li><li>Relative Humidity: 0 to 95%, non-condensing</li><li>AC Mode BTU / Hr. (Full Load): 39</li><li>AC Mode Efficiency Rating (100% Load): 99%</li><li>Audible Noise: 45 dBA maximum, front side 1m</li><li>Network Management Cards: SNMPWEBCARD; TLNETCARD ; WEBCARDLX </li><li>Network Monitoring Port Description: Supports detailed monitoring of UPS and site power conditions</li><li>PowerAlert Software: For local monitoring via the UPSrs built-in communications ports, download PowerAlert software at https://tripplite.eaton.com/products/power-alert</li><li>Communications Cable: USB and DB9 cabling included</li><li>WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications</li><li>Network Management Card Description: Network management card optional</li><li>Communications Interface: DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface; USB</li><li>Transfer Time: 5 milliseconds AC to DC; 1 millisecond DC to AC</li><li>Low Voltage Transfer to Battery Power (Setpoint): 83</li><li>High Voltage Transfer to Battery Power (Setpoint): 147</li><li>Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported</li><li>High Availability UPS Features: Auto Probe Monitoring and Reboot (requires WEBCARDLX); Automatic Voltage Regulation (AVR); Hot swappable batteries; Remote management; Surge/noise protection</li><li>Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS; Individually controllable load banks</li><li>Grounding Details: Back panel grounding lug</li><li>UPS Applications: Large Network; High-End Desktop/Small Network; Retail/Point of Sale; Hospitality</li><li>Product Certifications: CSA (Canada); NOM (Mexico); UL 1778</li><li>Product Compliance: RoHS; FCC Part 15 Class A (USA)</li><li>Product Warranty Period (Worldwide): 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.</li><li>Connected Equipment Insurance (U.S., Canada &amp; Puerto Rico): $250,000 Ultimate Lifetime Insurance</li></ul>
